Vehicle Classification
The Pajero Mini (chassis codes H53A, H56A-H58A) is built around two grade lines, distinguished primarily by engine state of tune. Both share the same 4A30 engine block but differ in valvetrain and induction.
Grade summary
| Grade | Valvetrain | Induction | Drivetrain | Transmissions |
|---|---|---|---|---|
| XR-I / XR-II | 4A30, SOHC, 16-valve | MPI (electronic multi-point fuel injection) | 4WD | 5-speed manual (5M/T) or 3-speed automatic (3A/T) |
| VR-I / VR-II | 4A30, DOHC, 20-valve | MPI with intercooled turbocharger | 4WD | 5-speed manual (5M/T) or 3-speed automatic (3A/T) |
- The XR grade is the naturally aspirated SOHC line.
- The VR grade is the DOHC intercooler-turbo line.
- Roman numeral suffixes (I / II) denote trim/equipment sub-variants within each grade rather than mechanical differences.
- Chassis code E-H56A appears against the MPI/turbo line in the source table.
Internal type/model codes
The manual’s classification table also lists internal factory codes (e.g. MNME, MNUE, MKUE, MNSF, MKSF, MNHF, MKHF) alongside transmission/drivetrain codes (V5M11, V3AS1, V5M41, V3AS2). The scanned table’s row/column alignment did not survive OCR cleanly enough to map each code to a specific grade/transmission combination with confidence.
(verified against scan p.13, 2026-08-30) — full code-to-configuration mapping confirmed visually against the page scan; see the resolved table below. Grade cell spans in the grid: XR-I covers MNME only; XR-II covers MNUE + MKUE; VR-I covers MNSF + MKSF; VR-II covers MNHF + MKHF. All rows fall under the single chassis code E-H56A and MPI electronic injection.
Full code-to-configuration mapping — RESOLVED (2026-08-30, re-shot p.13)
The classification grid, from a clean re-scan of printed p.13:
| Type code | Grade | Engine | Transmission |
|---|---|---|---|
| MNME | XR-I | 4A30 SOHC 16v | V5M11 4WD 5M/T |
| MNUE | XR-II | 4A30 SOHC 16v | V5M11 4WD 5M/T |
| MKUE | XR-II | 4A30 SOHC 16v | V3AS1 4WD 3A/T |
| MNSF | VR-I | 4A30 DOHC 20v intercooler turbo | V5M41 4WD 5M/T |
| MKSF | VR-I | 4A30 DOHC 20v intercooler turbo | V3AS2 4WD 3A/T |
| MNHF | VR-II | 4A30 DOHC 20v intercooler turbo | V5M41 4WD 5M/T |
| MKHF | VR-II | 4A30 DOHC 20v intercooler turbo | V3AS2 4WD 3A/T |
Pattern: MN- prefix = 5-speed manual, MK- prefix = 3-speed automatic. All are chassis E-H56A, MPI electronic injection.
Our truck’s VIN resolves to type MKPF3 in the EPC — a later-series code beyond this Dec-‘94 grid (VR-II Anniversary Limited, 3A/T), consistent with the MK-prefix = automatic pattern. Covered by manual supplements, not this base table.
