Rear bumper & support
This EPC family contains 1 catalog variation for the VIN-confirmed Pajero Mini H56A catalog.
Diagram 7939183
Parts diagram group Rear bumper & support in the VIN-confirmed megazip catalog for our H56A (type MKPF3).
Open diagram & live parts list on megazip
This locally archived diagram was supplied for personal reference. The part identifiers below are catalog facts,
verified-official, snapshot 2026-08-30.
Parts list (21 items)
Scraped from the megazip catalog page 2026-08-30 — verified-official. Ref = callout number on the diagram. Prices are megazip snapshot prices from the scrape date, not list prices — always re-check live before buying.
| Ref | Part No. | Name | Notes | Qty | Price (USD) |
|---|---|---|---|---|---|
| 64010 | MR208097 | BUMPER, RR | 1 | — | |
| 64010 | MR365157 | BUMPER, RR | 1 | $547.46 | |
| 64014L | MR208629 | BUMPER KIT, RR CORNER, LH | 1 | $155.40 | |
| 64014L | MR208673 | BUMPER KIT, RR CORNER, LH | 1 | — | |
| 64014R | MR208630 | BUMPER KIT, RR CORNER, RH | 1 | $155.40 | |
| 64014R | MR208674 | BUMPER KIT, RR CORNER, RH | 1 | $155.40 | |
| 64014R | MR344756 | BUMPER KIT, RR CORNER, RH | 1 | $155.40 | |
| 64992B | MF453108 | SCREW, ACCEL CONTROL EQUIP | Tapping,6x20 | 2 | $0.88 |
| 64992B | MS452348 | SCREW, STEERING COLUMN | 2 | $2.34 | |
| 64992C | MS350143 | SCREW, PARKING BRAKE LEVER | Washer assembled,6x16 | 6 | $2.74 |
| 64992C | MS350179 | SCREW, FR BUMPER | Washer assembled,6x16 | 6 | — |
| 64992C | MS350180 | SCREW, FOOTREST | Washer assembled,6x20 | 6 | $3.83 |
| 64994N | MS440503 | NUT | Washer assembled,8 | 1 | $0.64 |
| 64998P | MS240125 | BOLT, FUEL TANK | Washer assembled,8x20 | 4 | $0.88 |
| 64998P | MS240180 | BOLT, FR BUMPER | Washer assembled,8x20 | 5 | $0.35 |
| 64998P | MS240397 | BOLT, FR DOOR WINDOW | Washer assembled,8x20 | 4 | $5.06 |
| 64998Q | MB553187 | BOLT, P/S OIL PUMP | Washer assembled,8x20 | 1 | $3.56 |
| 64998Q | MS240125 | BOLT, FUEL TANK | Washer assembled,8x20 | 1 | $0.88 |
| 64998Q | MS240397 | BOLT, FR DOOR WINDOW | Washer assembled,8x20 | 1 | $5.06 |
| 64998Q | MS240586 | BOLT, BODY LOOSE PANEL | Washer assembled,8x25 | 1 | $4.92 |
| 64999 | MB481588 | GROMMET, FR BUMPER | Screw .,6 | 2 | $2.30 |
